dhtmlxConnector for grid
- client-side
- server-side

dhtmlxConnector for grid

client-side

index.html

<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml">
<head>
    <script src="codebase/dhtmlx.js" type="text/javascript"></script>
    <script src="codebase/connector/connector.js"></script>
	<script src="codebase/connector/dataprocessor.js"></script>
    <link rel="STYLESHEET" type="text/css" href="codebase/dhtmlx.css">
    <div id="gridbox" style="width:450px;height:250px";border:1px solid #A4BED4;></div>
<script type="text/javascript">



var mygrid,myDP;
function doOnLoad(){
    mygrid = new dhtmlXGridObject('gridbox');
	mygrid.setImagePath("codebase/imgs/");
	mygrid.setHeader("Name,Category,Ingredients");
	mygrid.attachHeader("#connector_text_filter,#connector_select_filter,#connector_select_filter");
	mygrid.setInitWidths("200,80,*");
	mygrid.setColTypes("ro,ed,ed");
	mygrid.setColSorting("str,connector,str");
	mygrid.init();
        mygrid.load("xml/griddata.php");

	myDP = new dataProcessor("xml/griddata.php");
        myDP.init(mygrid);

}
</script>
</head>
<body onload="doOnLoad()" >
</body>
</html>

server-side

griddata.php

<?php
require_once("../codebase/connector/grid_connector.php");

$res=mysql_connect("localhost","root","");
mysql_select_db("tasks");
$conn = new GridConnector($res);
$conn->enable_log("temp.log");

function custom_sort($sorted_by){
          if (!sizeof($sorted_by->rules))
               $sorted_by->add("group","DESC");
}
function formatting($row){
                  //render field as details link
				  if ($row->get_value("vegetarian")==1&$row->get_value("group")!='Drinks')
                                       $row->set_value("name"," <font color=#FF0066> Vegetarian!  </font>".$row->get_value("name")."");
	}
function validate($data){
             if ($data->get_value("group")=="")
                  $data->error();
}
$conn->event->attach("beforeProcessing","validate");
$conn->event->attach("beforeSort","custom_sort");
$conn->event->attach("beforeRender","formatting");

$conn->render_table("meals","id","name,group, ingredients", "vegetarian");

?>
